100 watts (4 x Svetlana ���Winged C��� EL34 - 6 x 12AX7)
2 fully independent channels (Channel 1 - Clean/Channel 2 - Crunch)
Both Channels feature Volume, Gain, Bass, Middle, Treble, Presence
Dual Volume/Gain Channel 2 (switchable, allows for two gain settings with 2 volumes for level adjustment to match volumes)
Rear panel low frequency 3-position adjustment switch allows for changing the amount and character of the bottom end - effects both channels)
2 button footswitch included for access to Ch 1/2 or Ch2 A/B
100v, 120v, 220v and 230/240v output selection
Ohm selector switch for 4, 8 or 16ohm output
Vintage look
All components specifically spec'd and tested by Diamond before inclusion in the product.
Independent LED's indicate which volume/gain is active and whether the boost is engaged.
Properly designed, tube-driven effects loop (shorting jack so the loop will automatically engage when cables are plugged in and disengage when cables are removed).
Front panel Effects Return control that acts as an overall master when loop is engaged for quick overall volume adjustment.
Point to point hand wired
